Crysalli has a variety of accessories and upgrade components available. All of the parts and pieces required to complete every installation. CO2 regulators, angle stop adaptors, wall mounting brackets, filters, faucets, leak block detectors & more. Placing the remote chiller in a ventilated cabinet? Consider an air baffle and/or our thermostatic fan box to improve air flow and ventilation. Need to free up valuable floor or cabinet space? Hang the remote chiller on the wall with a wall mounting bracket. Everything you need to make the system work.
CR-14FC Water Filter System
Features
- Compact size fits under the counter
- Removes the bad tastes, odors, colors and particles as small as 1/2 micron, while retaining the good minerals that are essential for bottle quality tasting water
Specifications
- System features on 4FC cartridge:
- Advanced Fibredyne technology
- Quick change sanitary cartridge
- Recyclable
- High capacity, extended filter life
- Manifold features water shut-off, flushing valve and water pressure gauge
- Certifications: NSF-42 Class I and NSF 53
- Inlet connection: 3/8″
- Outlet connection: 3/8″
- Flow rate: 2.5 GPM
- Rated capacity: 15,000 gallons
- Pressure requirements: 10-125 PSI
- No electrical connection
- 8.04″ Width
- 5.5″ Depth
- 15.23″ Height
CR-14FCP Water Filter System
Features
- Compact size fits under the counter
- Advanced Fibredyne media technology cartridges offer superior reduction in chlorine, taste, odor, color and organic chemicals while providing exceptional sediment reduction with resistance to premature plugging. This submicron technology is NSF certified to reduce particles as small as 1/2 micron in size which reduces health contaminants such as cysts
Specifications
- 2 stage system
- 10″ pleated cellulose pre-filter
- 4FC high capacity cartridge
- Advanced Fibredyne technology
- Quick change sanitary cartridge
- Recyclable
- High capacity, extended filter life
- Certifications: NSF-42 Class I and NSF 53
- Flow rate: 2.5 GPM
- Rated capacity: 15,000 gallons
- Inlet connection: 3/8″
- Outlet connection: 3/8″
- Pressure requirements: 40-125 PSI
- No electrical connection
- Manifold features water shut-off, flushing valve and water pressure gauge
- 14.254″ Width
- 6.13″ Depth
- 15.23″ Height
CR-24FC Water Filter System
Features
- Compact size fits under the counter
- Removes the bad tastes, odors, colors and particles as small as 1/2 micron, while retaining the good minerals that are essential for bottle quality tasting water
Specifications
- System features on 4FC cartridge:
- Advanced Fibredyne technology
- Quick change sanitary cartridge
- Recyclable
- High capacity, extended filter life
- Manifold features water shut-off, flushing valve and water pressure gauge
- Certifications: NSF-42 Class I and NSF 53
- Inlet connection: 3/4″
- Outlet connection: 3/4″
- Flow rate: 5 GPM
- Rated capacity: 30,000 gallons
- Pressure requirements: 35-125 PSI
- No electrical connection
- 16.60″ Width
- 5.5″ Depth
- 19.25″ Height
CR-24FCP Water Filter System
Features
- Compact size fits under the counter
- Advanced Fibredyne media technology cartridges offer superior reduction in chlorine, taste, odor, color and organic chemicals while providing exceptional sediment reduction with resistance to premature plugging. This sub-micron technology is NSF certified to reduce particles as small as 1/2 micron in size which reduces health contaminants such as cysts
Specifications
- 2 stage system
- 10″ pleated cellulose pre-filter
- Two 4FC high capacity cartridge
- Advanced Fibredyne technology
- Quick change sanitary cartridge
- Recyclable
- High capacity, extended filter life
- Certifications: NSF-42 Class I and NSF 53
- Flow rate: 5 GPM
- Rated capacity: 30,000 gallons
- Inlet connection: 3/4″
- Outlet connection: 3/4″
- Pressure requirements: 40-125 PSI
- No electrical connection
- Manifold features water shut-off, flushing valve and water pressure gauge
- 21.59″ Width
- 6.13″ Depth
- 19.25″ Height
CR-ABUCM Air Baffle Accessory Kit
Features
- For use with under counter models CR-UCM1 & CR-UCM2
- Minimizes recirculation of hot exhaust air into the air intake of the condenser
- Recommended anytime a remote chiller is installed in a cabinet
Specifications
CR-TFB1 Thermostatic Fan Box
Features
- Assists in removing trapped heat in a cabinet produced by UCM Remote Chiller
- Temperature controlled fan, automatically turns itself on or off depending on cabinet temperature
- Can be used with or without exterior side face plate
- Made in the USA
Specifications
- Digital thermostat
- Factory set at 90°F to turn on/off
- 117 CFM Fan
- 120 volt. 7′ electrical cord and plug
- Max amps: 0.5
- 4′ temp probe cord
- Overall dimensions: 9.5″W x 3″D x 7.875″H
- Exterior side face plate: 9.5″W x 7.875″H
- Requires a 7.5″ Width x 5.5″ Height cut out in cabinet panel
CR-WMB1 Wall Mount for CR-UCM1
Specifications
- For use with CR-UCM1 and CR-UCW-BH Remote Chillers
- Upward cantilever brackets for tighter, cleaner fit on wall
- With the legs removed off the CR-UCM1, it will sit on top of the rack and is bolted from the bottom up through the leg bracket holes with 5/16-18 1″ bolts
- WMB1 should be mounted to a wall with appropriate backing and bracing anchors to support the full weight of the CR-UCM1
- Allow for 8″ of clearance above unit to access water bath
CR-WMB2 Wall Mount for CR-UCM2
Specifications
- For use with all CR-UCM2 series configurations: CR-UCM2, CR-UCM2-S0096, CR-UCM2-2CL, and CR-UCM2-SW2
- Upward cantilever brackets for tighter, cleaner fit on wall
- With legs removed off the CR-UCM2, it will sit on top of the rack and is bolted from the bottom up through the leg bracket holes with 5/16-18 1″ bolts
- WMB2 should be mounted to a wall with appropriate backing and bracing anchors to support the full weight of the CR-UCM2
- Allow for 8″ of clearance above unit to access water bath
CR-LBS10JG Leak Block Sensor With Auto Shut-Off
Features
- Peace of mind; protect your floors or cabinets from leaks
- In-line leak detector with auto shut-off
- Can be used with any Crysalli chiller system
Specifications
- Audible beep when water leak is detected
- Auto shut-off of the water at the solenoid when water is detected
- Uses 9v battery
- Auto shut-off and beep when battery needs replacement
- 3/8″ quick connect fittings
- 38″ solenoid valve cord
- Max operating pressure: 125 psi
- Max flow rate: 5 GPM
- Sensor designed to fit next to chiller unit
CR-BG2B-FF Bar Gun Two Button
Features
- ETL Sanitation Listed – Conforms to NSF 18
- Nozzle removes easily with no tools for cleaning & sanitizing
- Never becomes stuck to inner nozzle
- Double o-ring fittings help prevent leaks
- Low maintenance and life cost
- Easy removal from bar with no tools
- Holster unit removable with no tools for easy cleaning
- Large drain tube from holster prevents backup (1/2” ID)
- Holster design helps prevent nozzle from contamination
Specifications
- Bar gun designed for fast flow dispensing of sparkling and still water
- Two button configuration
- 30″ long hose
- Mechanical shut-off and metering controls
- 3/8″ quick connect fittings
- Twist off nozzle for cleaning
- Comes with holster and drain assembly
- For use with CR-UCM1 or CR-UCM2 Remote Chillers
CR-WBM-4004 Flavor & Water Bar Gun
Features
- Flavor and water bar gun
- Six button:
- Four syrup
- One rinse
- One sparkling water
- Regular flow
CR-WBM-604 Flavor Shot Bar Gun
Features
- Flavor shot bar gun
- Five button:
- Four syrup
- One rinse
- Regular flow
CR-804-001 Low Volume Water Boost System
Features
- Increases flow and pressure to sparkling and still water systems
- Ideal for applications where dynamic water pressure to filter systems is lower than 45 PSI
- Maximizes filter life on filtration systems
- Self priming pump can run without damage
- Eliminates water pressure fluctuation at point of dispense
- Low profile allows for under counter installation
- Complete turn-key package
- NSF certified components
Specifications
- Accumulator: 24 oz glass filled nylon accumulator
- Pre-charge with 40 PSI air at time of installation
- 90 PSI boost
- Max Draw Down: 10 oz
- Water inlet/outlet connections: 3/8” JG push-fit connections
- Operating temperature range: 34°-120°F
- Electrical: 115 VAC/1 Amp
- Weight: 8 lbs
- 9.84”W x 10.24”D x 4.6”H
- Install water boost prior to filtration system
CR-804-023 Water Boost System
Features
- Increases flow and pressure to sparkling and still water systems
- Ideal for applications where dynamic water pressure to filter systems is lower than 45 PSI
- Maximizes filter life on filtration systems
- Replaceable bladder for maximum system life and simple maintenance
- Self priming pump can run without damage
- Eliminates water pressure fluctuation at point of dispense
- Low profile allows for under counter installation
- Rigid stainless steel tanks
- Complete turn-key package
- NSF certified components
Specifications
- Accumulator: 2 gallon stainless steel accumulator
- Pre-charge with 50 PSI air at time of installation
- 90 PSI boost
- Max Draw Down: 0.75 gallons
- Water inlet/outlet connections: 3/8” JG push-fit connections
- Operating temperature range: 34°-120°F
- Electrical: 115 VAC/1 Amp
- Weight: 13 lbs
- 13”W x 13.5”D x 9.5”H
- Install water boost prior to filtration system
CR-804-026 Water Boost System
Features
- Increases flow and pressure to sparkling and still water systems
- Ideal for applications where dynamic water pressure to filter systems is lower than 45 PSI
- Maximizes filter life on filtration systems
- Replaceable bladder for maximum system life and simple maintenance
- Self priming pump can run without damage
- Eliminates water pressure fluctuation at point of dispense
- Low profile allows for under counter installation
- Rigid stainless steel tanks
- Complete turn-key package
- NSF certified components
Specifications
- Accumulator: 6 gallon stainless steel accumulator
- Pre-charge with 50 PSI air at time of installation
- 90 PSI boost
- Max Draw Down: 2.3 gallons
- Water inlet/outlet connections: 3/8” JG push-fit connections
- Operating temperature range: 34°-120°F
- Electrical: 115 VAC/1 Amp
- Weight: 18 lbs
- 19”W x 16”D x 12”H
- Install water boost prior to filtration system
CR-SDL-SSX1 Lever activated, faucet assembly
Sanitary dispense lever with stainless steel faucet
- Rigid stainless steel lever, extends 1.75″ below nozzle
- Self closing, spring loaded
- Downward pointing nozzle
- Comes with optional stainless steel tap cap
- Use on custom draft towers and as a retrofit kit for CBR towers
Features
- Robust, stainless steel faucet design
- Integrated stainless steel adjustable flow compensator
- Touchless stainless steel lever activated dispense
- Easy to clean
- User and maintenance friendly
- ADA friendly
- Adapts to CBR and other Crysalli towers
- Use on custom draft towers for self service use
CR-SDL-1 Assembly components
- SSX0101 faucet with shank and ring
- Stainless steel sanitary lever
- Optional stainless steel pivot ball cap
- Threaded jam nut for use with ergo handle
- Two piece pivot ball mounting clamp
- 3/32” hex wrench
- 4-40 SS screws
CR-SDL-1 Universal, lever activated, faucet assembly
Sanitary dispense lever compatible with:
- X0101-B-HEX-SC
- Black speedy valve, self closing bent nozzle, hex adjuster.
- Standard faucet on CR-1, CR-2 and other countertop Crysalli models and the CM-V2W tower
Features
- Robust, stainless steel faucet design
- Integrated stainless steel adjustable flow compensator
- Touchless, stainless steel lever activated dispense
- Easy to clean
- User and maintenance friendly
- ADA friendly
- Ideal for self service applications
CR-SDL-1 Assembly components:
- Stainless steel sanitary lever
- Optional stainless steel pivot ball cap
- Threaded jam nut for use with ergo handle
- Two piece pivot ball mounting clamp
- 3/32” hex wrench
- 4-40 SS screws
CR-CTAC Gas Cylinder Auto Changeover Device
Device Options:
- CR-CTAC-2CK
- CO2 cylinder auto change device. Two cylinder kit, includes two 36″ hoses with check valve and tank fittings, wall bracket and CR-3741 high pressure primary CO2 regulator.
- CR-NTAC-2CK
- N2 cylinder auto change device. Two cylinder kit, includes two 36″ hoses with check valves and tank fittings, wall bracket and CR-742N primary N2 regulator
Features
- Run two gas cylinders at one time
- Automatically switches over empty gas cylinder to new full one
- Doubles the amount of gas in use
- Can be used with 5 lbs through 50 lbs cylinders
- Great for high volume customers that can’t use bulk cylinders
- Can double the volume of smaller tanks in cabinets
- Priority Select feature allows you to designate which cylinder is considered primary
- Installation is quick and simple
- No electrical, operates with pressures
- Optimizes route planning
- Ensures a continuous supply of gas
- Reduces frequency of changing cylinders
Specifications
- 6” W x 4.6” H x 2” D
- Gas service: Inert
- Inlet (2) and Outlet (1): 1/4” NPT
- Safety: Self-resetting 175 psi
- 3,000 PSI gauges
- 36” High pressure metal braided hose
- Non-electrical
Sierra Filtration Services Custom Water Solutions
